FTTH Drop Cable Production: Manufacturing Process Explained
Surprising fact: in excess of seventy percent of U.S. broadband rollouts now depend on fiber networks that demand precise manufacturing to achieve required performance.
Shanghai Weiye OFC Equipment handles end-to-end SZ stranding line manufacturing, from selecting brand fibers like Fujikura or Corning SMF-28e to final test reports that deliver 100% QA.
Our FTTH drop designs fit aerial, underground, and direct burial installation, with LSZH, polyvinyl chloride (PVC), and polyethylene (PE) jacket options and core counts from 1 to 4 cores. We provide single-mode OS1/OS2 and OM2–OM4 grades plus ITU-T G.652D and G.657 variants, Pantone-matched sheath colors, and logo printing.
Automated machines and precision equipment keep line speed steady and keep repeatability high. Typical lead times run four to five days for orders under 100 km and seven to ten days for < 500 km, with an min. order of 1 km and free-replacement warranty for quality problems.
Continue to understand how materials plus testing and support combine to lower lifecycle cost and match the right product to your network system.
- Shanghai Weiye OFC Equipment offers full manufacturing with lab validation for United States projects.
- A range of jacket options and optical grades cover varied installation environments.
- Automated lines and machines deliver stable quality and reliable optical performance.
- Quick lead times, low minimums, and recognized brand fibers keep procurement predictable.
- Complete reports and after-sales warranty support product reliability and documentation needs.
FTTH Manufacturing Expertise by Shanghai Weiye OFC Equipment
When schedules and performance count, Shanghai Weiye OFC Equipment delivers tailored drop solutions with complete test documentation.
As a specialized maker and supplier, Shanghai Weiye OFC Equipment pairs purpose-built equipment with stringent material control. We offer custom builds and services for residential/MDU deployments. Every order comes with 100% quality assurance and complete test reports.
Our lab runs high-temperature, salt-fog, and vibration testing to verify durability. Jacket options cover LSZH, PVC, and PE. Designs cover flat bow-type and self-supporting styles and support brand fibers such as Fujikura® and Corning® SMF-28e.
- Documented line control and production checks for auditable shipments.
- Engineering support for specs, trials, and ramp to volume.
- Modern fixtures and calibration reduce variability so every cable matches operator specs.
FTTH Cable Production
At Shanghai Weiye OFC Equipment, manufacturing steps are built around network requirements, combining brand fiber choices with disciplined test flows.
Optical fiber selection and brand options
We select fiber draw tower to bend radius, attenuation, and deployment type. Options include OS1/OS2 and OM2–OM4 and ITU-T G.652D, G.657.A1/A2. Brand fibers such as Fujikura® and Corning SMF-28e are offered to meet procurement standards.
Integrating Strength Members
Strength members use FRP (dielectric) or metallic steel wire. FRP is ideal where non-conductive runs are required. Steel wire adds tensile strength for longer aerial spans and bonding/grounding needs.
Jacket extrusion and process control
Jacket options include LSZH for indoor flame safety, PVC for flexibility, and PE for outdoor UV and moisture resistance. Closed-loop control of extruder temperature and capstan speed keeps line speed stable and critical dimensions.
| Member | Dielectric FRP | Metallic Steel |
|---|---|---|
| Use case | Non-conductive runs | High-tension aerial runs |
| Key benefit | Lightweight, inert | High strength |
| Installation note | Easier terminations | Requires grounding |
Testing & Verification
Inline geometry/concentricity checks run during manufacturing. Final optical tests verify loss and reflectance. Each order includes a full test report and lab results from high-temperature, salt-spray, and vibration tests to qualify field handling and drop terminations.
Typical lead times are 4–5 days for < 100 km and under 500 km in 7–10 days. Material lot records and first-article approvals provide traceability and compliance for U.S. projects.
FTTH drop cable types and structures we manufacture
Shanghai Weiye OFC Equipment offers a compact portfolio of FTTH drop designs that fit indoor risers and long aerial runs. Each option combines tested materials with field-termination geometry and consistent optical performance.
The bow-type flat drop cable keeps a small footprint for risers and conduit. It keeps bend loss low for easy routing in MDU corridors and hallways.
Aerial Self-Supporting Options
Self-supporting FTTH drop designs use a support messenger to carry tensile loads. Choose dielectric FRP for electrical isolation or steel wire when bonding and higher tensile strength are required.
Layouts & Strength Members
We offer dielectric and metallic strength member configurations to meet safety/EMI requirements. Central loose-tube and unitube flat types balance crush resistance and compact fiber unit for fast terminations.
Jackets for Indoor/Outdoor
Jacket choices include LSZH for flame-retardant, low-smoke indoor use and PE for outdoor UV and moisture resilience. Each family is qualified for mechanical/optical performance before shipment.
| Design | Application | Strength member | Jacket |
|---|---|---|---|
| Flat bow-type | Indoor risers and MDUs | Dielectric FRP | LSZH |
| Self-supporting (aerial) | Overhead spans | FRP/Steel | Polyethylene |
| Center loose tube | Higher fiber counts | Dielectric FRP | LSZH/PE |
| Unitube flat | Low count, quick strip | FRP/Steel | LSZH/PE |
Equipment Ensuring Quality and Throughput
Automation with sensor feedback at Shanghai Weiye OFC Equipment cut manual handling and increase throughput for drop patch preparation.
Our production line uses automated machines that cut/strip drop cords to increase output and cut labor variability.
The CLX-BPO2 automated stripper uses PLC + photoelectric control. One cycle is ~1.5 s, giving real-world speeds near 20 terminal operations per minute.
Auto Cut & Strip Capabilities
The equipment strips LSZH and PVC jackets and trims FRP/steel members to precise reserved lengths. Pneumatic cylinder actuators deliver fast, repeatable motion and low downtime.
PLC & Photoelectric for Precision
PLC logic and photoelectric sensors deliver precise positioning and closed-loop control. Inline checks feed control charts so operators can adjust drifts before defects grow.
| Item | Spec | Benefit |
|---|---|---|
| Machine | 1.5s cycle, auto-strip | ~20 terminals/minute throughput |
| Actuation | Cylinder-based | High speed and reliability |
| Material handling | LSZH/PVC; FRP/steel | Accurate stubs, clean terminations |
| Control | PLC + photoelectric + inline checks | Stable quality, reduced rework |
- Automated waste ejection and ergonomic loading keep the line clean.
- Process control plans capture calibration intervals and critical parameters.
- Combined machines, fixtures, and trained staff support FTTH volume targets without compromising accuracy.
CLX-BPO2 Capabilities on Our Line
The CLX-BPO2 provides industrial-grade strip/trim to our line, cutting cycle time while keeping prep consistent.
Shanghai Weiye OFC Equipment deploys the CLX-BPO2 to increase throughput and standardize terminal quality. The unit cycles in ~1.5 seconds, producing around 20 preps per minute in production.
PLC and photoelectric control enable precise detection and repeatable actuation. That control helps keep strip lengths and reserved strength stubs within tight tolerances.
Throughput & Cycle Time
Typical operation speed is 1.5s per cycle. This enables steady throughput under continuous line conditions.
Jacket Strip & Stub Lengths
The CLX-BPO2 handles LSZH/PVC with an adjustable jacket strip length from 17.5 to 35.0 mm. Reserved stubs are adjustable from 7.0–11.0 mm to fit common termination hardware.
Handling FRP and steel wire strength members
The machine cuts FRP/steel strength elements cleanly while protecting adjacent fibers. Customized cutters are offered for nonstandard sizes to maintain precision.
- Auto-eject scrap and sensor start reduce idle time.
- Small footprint (L40 × W18 × H18 cm), 50W at 110–220V, and 11 kg mass simplify cell integration.
- Cylinder-driven motion and closed-loop control boost reliability and lower maintenance interruptions.
| Spec | Rating | Benefit |
|---|---|---|
| Cycle | ≈1.5 s (~20/min) | Supports high-volume runs |
| Strip lengths (A) | 17.5–35.0 mm | Compatible with common connectors |
| Stub (B) | 7.0–11.0 mm | Supports termination strength |
| Power & size | 110–220V, 50W; 40×18×18 cm | Easy integration into existing equipment |
Using this machine, Shanghai Weiye OFC Equipment standardizes terminal prep so field teams get drop parts install-ready. The CLX-BPO2 helps our production lines meet volume goals without sacrificing quality.
Tailored Specifications for Your Network
Shanghai Weiye OFC Equipment configures each build to fit your network requirements and simplify deployment. We combine focused options with predictable schedules so your teams receive ready-to-install products.
Choose 1 to 4 cores with single-mode or multimode fiber. Options include OS1/OS2 plus OM2–OM4 plus G.652D/G.657 variants to align with optics and connector plans.
We match sheath colors to Pantone codes for quick field identification and consistent asset tagging.
Jacket materials, print legends, and branding
Select LSZH/PVC/PE jackets to suit route and safety requirements. Custom legends/logos support inventory and warranty tracking.
Put-Ups, Packaging, and Structures
Standard put-ups are 1 km, 2 km, and 4 km with tailored reels and packaging to fit storage/handling. Choose flat bow-type or self-supporting and steel wire or FRP strength members to fit span and isolation requirements.
| Option | Common choice | Benefit |
|---|---|---|
| Reel length | 1 / 2 / 4 km | Less staging, easier reels |
| Sheath | LSZH, PE, PVC | Indoor/Outdoor fit |
| Design | Bow-type / Self-supporting | Flexible routing/span |
As a supplier, Shanghai Weiye aligns runs to your schedule and provides docs that lists final specifications for straightforward QA on site.
QA, Testing & Documentation
Shanghai Weiye OFC Equipment builds checkpoints into production so every item has recorded acceptance data at ship.
Environmental and Mechanical Tests
Our lab runs high-temperature exposure, salt spray corrosion, and vibration tests to qualify materials/assemblies. These tests simulate field stresses for indoor and outdoor use.
Per-Reel 100% Reports
Every fiber optic cable includes a 100% test report that records loss, return loss, and key geometry where applicable. Final inspection gates stop nonconforming items before they leave the factory.
Audit Trail and Compliance
Batch records tie test data to reels and serials so audits and claims are easy to verify. Documentation follows common customer templates to speed approvals and inbound inspection.
- Line checks and final inspection prevent field failures and cut warranty events.
- QA packages include spec confirmation and formatted test data for quick review.
- Continuous test trends inform preventive maintenance and improve long-term reliability.
| Trial | Why | Result |
|---|---|---|
| Heat exposure | Material stability | Validated heat endurance |
| Salt spray | Corrosion robustness | Qualified for outdoor use |
| Mechanical vibration | Mechanical robustness | Improved field reliability |
Cost Drivers and Pricing
Budgeting for a drop run starts with fiber and jacket choices and is refined by volume and customization.
Typical prices range broadly—from about $30–$1,000 per unit—based on fiber grade (G.652/G.657/OM2–OM4), jacket material, reel length, and design structure.
Material choices, fiber grade, jacket type, and structure
The primary cost drivers are fiber grade, sheath material, and the chosen structure for deployment.
Self-supporting designs and steel members increase material/labor. Custom colors, logos, and print legends add setup and influence price for short runs.
Order length, volume, and customization impact on price
Longer put-ups and larger volumes reduce unit cost. Small quantities often carry setup fees and higher unit prices.
- Changeovers and special cutters extend lead time and add cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Frameworks and indexed pricing stabilize budgets across phases.
| Driver | Price impact | Recommendation |
|---|---|---|
| Fiber grade | Large | Balance spec vs. budget |
| Jacket type | Medium impact | Compare LSZH vs. PE for total cost |
| Order length / volume | High impact | Consolidate where possible |
Lead times, MOQ, and delivery for the United States
Shanghai Weiye OFC Equipment keeps lead times/logistics clear so planners can align crews and sites. Predictable schedules reduce downtime and help control cost when a rollout is underway.
Production Windows & Capacity
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for < 500 km. We plan capacity to track your milestones and to keep deliveries on time.
The service team provides updates/tracking so installation teams can plan arrivals. For compressed schedules, we reserve contingency capacity to pull in critical-path orders.
Minimum order quantity and why it matters
The MOQ is one kilometer. This reflects line setup such as wire and jacket die adjustments that use startup material and generate scrap.
We review your length and staging plans to select reels to reduce waste/handling. Batch releases can balance inventory holding with frequent, smaller deliveries to job sites.
Where and How to Deploy
Site conditions dictate whether a self-supporting span, duct pull, or direct-buried run is the best fit for a project.
Deployment Considerations
For aerial runs, Shanghai Weiye OFC Equipment recommends self-supporting designs with appropriate members to control sag and tension for long-term stability.
Duct installations work best with low-friction jackets and crush-resistant builds so pulling avoids fiber damage. PE jackets are typical for underground and buried paths where moisture resistance matters.
Direct-buried designs require proper depth control per local codes and moisture barriers to protect the fiber core long-term.
Indoor Riser/Plenum & ONT
Indoor riser/plenum routes favor LSZH jackets to meet smoke/flame codes. Flat drop profiles strip clean and present controlled stubs for quick ONT termination.
We guide the choice of steel or FRP (dielectric) strength members based on bonding needs, lightning exposure, and hardware compatibility. Standardized line prep shortens install time and reduces scrap.
| Scenario | Key feature | Installer note |
|---|---|---|
| Overhead | Self-supporting, steel or FRP | Check tension and messenger hardware |
| Underground duct | Low-friction jacket, crush resistance | Use pull tape + lubricant |
| Direct burial | PE jacket, moisture barrier | Follow local depth and warning tape rules |
| Indoor | LSZH jacket, tight bend support | Maintain bend radius at wall penetrations |
Our approach delivers a consistent installation across indoor/outdoor transitions. That reduces callbacks, faster activations, and stable field performance for your system.
End-to-end support and after-sales service
Our team coordinates testing, scheduling, and installation guidance to remove surprises during deployment.
Shanghai Weiye OFC Equipment offers engineering support from early requirements through approved drawings and pilot builds. We deliver documentation templates and clear installation notes so field crews work from the same plan.
After-sales service includes fast response, RCA, and corrective action. All products ship with full test reports and traceability to support QA acceptance.
- Round-the-clock availability for status and technical support.
- Warranty with free replacement if any quality problems are confirmed.
- Schedule coordination for urgent changes or acceleration requests.
- Configuration control so shipped items match agreed specs consistently.
| Area | Scope | Benefit |
|---|---|---|
| Engineering | Specs + pilots | Fewer field issues |
| QA/Testing | Lab + 100% reports | Full traceability |
| Service | Rapid replacement & root-cause | Minimized downtime |
Wrap-Up
Choose Shanghai Weiye OFC Equipment for tailored drop builds, short lead times, and traceable quality records.
We provide custom FTTH drops that combine materials with validated manufacturing and lab tests. Every reel ships with a 100% test report and documented trials to support U.S. field acceptance.
A hardened production line, including CLX-BPO2 prep assets, cuts variability and shortens turnaround. Our equipment set standardize strip/stub lengths so installers get consistent results at turn-up.
From fiber selection through jacket, printing, and packaging, we balance performance and cost to extend service life. Dedicated customer support covers scheduling/logistics/after-sales so your deployment remains on plan.
Contact Shanghai Weiye OFC Equipment to align specifications, timeline, and volume. We stand behind every fiber optic and optic cable shipment with lab validation and responsive service.
